Ku-band Satellite Internet Phased Array Terminal
- Automatically collects latitude, longitude, and orientation of the carrier and displaysantenna azimuth and elevation angles
- Matches Ku-band satellite resources
- Real-time output of carrier position and attitude information
- One-click satellite alignment with automatic adjustment to satellite with input satelliteparameters
- Polarization direction auto-switching
- Supports two satellite tracking methods: real-time program tracking and automatic tracking
- Records operational status in real time
- Features power-off memory and protection
TECHNICAL PARAMETERS
| Items | Parameters | Remarks | |
| Working Frequency | Tx | 13.75~14.5GHz | |
| Working Frequency | Rx | 10.7~12.75GHz | |
| Beams | Tx | 1 | |
| Beams | Rx | 1 | |
| EIRP | 83dBm@14.4GHz | Normal Direction | |
| G/T | >15dB/K@11.7GHz | Normal Direction | |
| Scanning Range | Azimuth | 0°~360° | |
| Off-Axis Angle | ±70° | ||
| Polarization Isolation | ≥30dBc @14.1GHz | ||
| Polarization | Arbitrary Linear Polarization | ||
| Power Consumption | <1500W | Support all/part Array shutdown for energy saving | |
| Power Supply | 220V | ||
| Dimensions | 1571mm*863mm*57mm | ||
| Weight | <48kg | ||
| Interfaces | IF Interface | TNC-K | |
| Control Interface | Circular Connector | ||
| Power Interface | Circular Connector | ||
